SI-50170-G RJ45 Modular Jack Tab-up ATA6616C-P3QW-1 Embedded IP-PBX

Name: SI50170G RJ45 Modular Jack Tabup ATA6616CP3QW1 Embedded IPPBX
Brand: LINK-PP
Price: 0.05 USD

Best SI-50170-G RJ45 Modular Jack Tab-up ATA6616C-P3QW-1 Embedded IP-PBX wholesale

Brand Name : LINK-PP

Model Number : LPJ1014AHNL

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000/25K

Price : $0.05-$1.28

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

part Number : SI-50170-G

Made In China : SM-LPJ1014AHNL

Original Munafactuer : LINK-PP

Application : 10/100 Base-T

LEDs : Optional

Samples : Available

Contact Now

SI-50170-G RJ45 Modular Jack Tab-up ATA6616C-P3QW-1 Embedded IP-PBX

Quick Details

1.10/100Base-T SIngle Port Rj45 Tab-UP Applications

2.1X1, INT. MAG., LED, REVERSE LATCH

3.SI-50170-G

4.SM-LPJ1014AHNL

4.LED optional, EMI-finger Optional.

SI-50170-G Electrical Specification: TEST NOTES(25±5℃)
1.TR:(100KHZ,100mV);
TX=1CT:1CT ±3% RX=1CT:1CT ±3%P2.LX:(100KHZ,100mV,8mA,DC Bias)
PINS:(P1,P3),(P4,P6)=350uH MIN
3.HIPOT:
PINS(P1,P2,P3)TO (J1,J2)=1500V
PINS(P4,P5,P6)TO (J3,J6)=1500V
4.INSERTION LOSS:
-1.0dB MAX @ 1.0MHz TO 65MHz
5.RETURN LOSS:
-20dB MIN @ 1MHz TO 10MHz
-16dB MIN @ 10MHz TO 30MHz
-12dB MIN @ 30MHz TO 60MHz
-10dB MIN @ 60MHz TO 100MHz
6.CROSS TALK:
-40dB MIN @ 1MHz TO 30MHz
-35dB MIN @ 30MHz TO 60MHz
-30dB MIN @ 60MHz TO 100MHz
7.COMMON TO COMMON MODE REJECTION:
-30dB MIN @1MHz TO 50MHz
-20dB MIN @50MHz TO 150MHz
8.Operating Temperature: 0℃～70℃.
